Fuel gas heat conduction oil furnace
- Heat power
120KW-14000KW
- Fuel
Various kinds of oil and gas
- Max.outlet oil temperature
350℃
Email:[email protected]
Introduction
| Heat power | 120KW-14000KW |
| Fuel | Various kinds of oil and gas |
| Max.outlet oil temperature | 350℃ |
Compared with steam boilers, heat transfer oil furnaces can obtain higher working temperatures at lower operating pressures, and have the technical characteristics of low pressure and high temperature. Stable at all levels of load with optimum thermal efficiency. With complete operation control and safety monitoring devices, it is convenient to operate, safe and reliable. Closed circuit circulation, liquid phase transportation of heat energy, small heat loss, significant energy-saving effect, low operating cost.
Quick installation or assembly factory, convenient transportation, short installation cycle, and fast production results. Compact structure, can be arranged separately, boiler room investment saving. The boiler has good thermal insulation performance, adopts high-efficiency insulation materials and advanced construction technology, heating with small heat loss of the furnace wall and accurate temperature regulation to meet different requirements.
Heat transfer oil furnace (organic heat carrier heating furnace) is based on coal, heavy oil, light oil, combustible gas and other combustible materials as fuel, heat transfer oil as heat carrier. The circulating oil pump is used to force the liquid phase circulation, and the heat energy is transferred to the thermal equipment, and then returned to the reheated direct-flow special
Parameter
| Model | Heat power | Max.outlet oil temp. | Shipping size（m） |
| YYQW-120-YQ | 120KW | 350℃ | 1.6×1.02×1.52 |
| YYQW-240-YQ | 240KW | 350℃ | 1.93×1.23×1.86 |
| YYQW-350-YQ | 350KW | 350℃ | 2.1×1.39×2.05 |
| YYQW-500-YQ | 500KW | 350℃ | 2.2×1.39×2.05 |
| YYQW-700-YQ | 700KW | 350℃ | 3.24×1.47×2.26 |
| YYQW-1000-YQ | 1000KW | 350℃ | 3.3×1.67×2.48 |
| YYQW-1200-YQ | 1200KW | 350℃ | 3.83×1.77×2.58 |
| YYQW-1400-YQ | 1400KW | 350℃ | 4.14×1.9×2.78 |
| YYQW-1800-YQ | 1800KW | 350℃ | 4.6×2.0×3.05 |
| YYQW-2100-YQ | 2100KW | 350℃ | 5.02×2.05×3.08 |
| YYQW-2400-YQ | 2400KW | 350℃ | 5.08×2.2×3.18 |
| YYQW-3000-YQ | 3000KW | 350℃ | 5.98×2.42×3.4 |
| YYQW-3500-YQ | 3500KW | 350℃ | 6.55×2.47×3.63 |
| YYQW-4700-YQ | 4700KW | 350℃ | 7.28×2.57×3.76 |
| YYQW-6000-YQ | 6000KW | 350℃ | 7.8×3.05×3.8 |
| YYQW-7000-YQ | 7000KW | 350℃ | 8.2×3.05×3.8 |
| YYQW-10000-YQ | 10000KW | 350℃ | 10×3.5×4 |
Advantages
- 1High output heat, high outlet temperature and low pressure.
- 2Under the same outlet temperature conditions, the cost of heat transfer oil boiler is low.
- 3The heat transfer oil boiler has few auxiliary machines and a small footprint, which is suitable for general small manufacturers.
- 4Generally, wood factories, floor factories, and furniture factories use this kind of boiler.
- 5Clean and pollution-free energy.
Application
-
wood industry
it is mainly used for hot pressing of fiberboard, particle board, laminate, plywood, veneer and heating of wood drying equipment, drying equipment, coating equipment and gluing machines.
-
building materials industry
it is mainly used for gypsum board drying, concrete component solidification protection and prefabrication production, tile molding, decorative material drying and linoleum production line heating.
-
road construction projects
it is mainly used for asphalt heating, dissolution, asphalt silage tank, asphalt concrete and emulsified asphalt heating and insulation.
-
textile printing and dyeing industry
it is mainly used for heating drying and setting devices, hot melt dyeing devices, dyeing and printing devices, dryers, dryers, calenders, flatteners, washing machines, rolling mills, ironing machines, hot air stwelfare, etc.
-
automobile industry
it is mainly used for the heating of tunnel drying rooms, skimming baths and phosphoric acid treatment equipment.
-
coking industry
it is mainly used for heating and heat preservation of gas storage tanks, mixing stations and distribution stations.
-
national defense scientific research
it is mainly used for high-temperature heat sources required for the development of new technologies, new materials and new products in national defense scientific research.
-
carbon industry
it is mainly used for graphite electrodes, carbon products, asphalt melting, kneading pot heating, extrusion heating.
-
maritime industry
it is mainly used for heavy oil tanks, asphalt tanks, sulfur tanks on ships and containers that need to be heated and insulated.
